Fixings In Cable Management
With such a range of cable management options available, from light cable trays to heavy trunking, the choice of fixing for installation should factor in both the weight of the cable management solution and the cable that carries it. Expert advice should be sought from structural engineers on site, or fixing manufacturers should carry on the weight of fixing themselves. In heavy load cases, anchor bolts or brackets may be used to securely secure things.
What Is A Cable Tray System?
A device or group of units and fittings that together constitute a sturdy structure to hold or support electrical cables and raceways is known as a cable tray system. It allows the safe transport of wires in open spaces and is effectively the structural component or skeleton of the building’s electrical system.
What types of cable management systems are there?
Depending on the kind of cable and the building or region where the system is being put, there are many different alternatives for containment systems. Some of the most common include:
- Cable baskets-lightweight and easily connected, these are usually clipped together allowing them to be installed quickly. They may be used for many other types of cable that have more advanced insulation, but they are frequently used for Category 5A and Category 6 TCP/IP data cabling. It includes PVC / PVC 6242y, MICC, fireproof or steel wire Armored Cable.
- Stair racking and tray work – mostly used for industrial installations as well as MICC and other small soft-skinned cables. For heavier cables, especially armored cables, there is ladder racking since it can support greater weight than cable baskets.
What is a conduit system?
Electrical ducts are tubes used for protecting and routing wires and fall into a category of materials depending on installation conditions – for example, if it is damp somewhere, PVC or galvanized metal should be used. When conduits safeguard the cable’s insulation from harm and lower the likelihood of problems, they may be employed for complete systems as well as individual thermoplastic or XLPE cables.
The grooves are secured using the saddle. As standard these are spacer bar saddles, but distance saddles can be used to fix the drain on uneven surfaces, while hospital saddles – which have a thicker base – allow easy cleaning around the drain in places where hygiene is a concern.
Conduit systems allow wiring systems ‘drops’ for electrical cable tray equipment yet to be installed, meaning construction work can be completed and cables can be pulled later.
The length of the conduit is connected to the coupling. Where a groove enters a box with no thread entry, it is terminated by coupling and brass bushing to complete the connection.
What Is A Running Coupling?
If the two systems cannot be screwed together, a running coupling can be rectified using two standard couplings, a nipple, a locknut, and extra-long threaded groove lengths. These are potential areas of weakness in the drain and are ideally avoided.
What Is A Trunking System?
Trunking, which is frequently used for single insulated cable, is a flexible technique to transport a variety of cable types since it can be folded and joined in intricate patterns. The usual earth fault loop impedance in trunking systems is frequently lower than anticipated because conduits and trunking systems effectively function as parallel conductors.
What Is Mini-Trunking?
Mini-trunking can be used in place of bigger PVC trunking systems with little cables, such as in smaller offices. It frequently has a self-adhesive backing that makes it simple to adhere to a wall.
What Is Dado Trunking?
Dado trunking is frequently utilized in workplaces or structures with a large number of data and power outlets. The trunking’s several compartments enable the almost simultaneous trunking of telephone, power, and data cables while keeping them apart from one another. Because of its extreme adaptability, outlets may be moved after installation if necessary.
